Heavy Load Ball Linear Motion Guide Rail for CNC Lathe

Short Description:

Linear guides are widely used in various automation fields, such as photovoltaic equipment, laser cutting, cnc machine and so on. We choose linear guides as their important components. Since the mode of friction between the linear guide slide and the slider block is rolling friction,the friction coefficient is minimal,which is only 1/50 of the sliding friction.The gap between the kinetic and static friction forces becomes very small, and it will not slip even in small feeds,so the positioning accuracy of the μm level can be achieved.

Model Size: 65mm

Brand: PYG

Rail Material: S55C

Block Material: 20 CRmo

Sample: available

Delivery time: 5-15 days

Precision level: C , H, P, SP, UP

Send email to us Whatsapp

Product Detail

Product Tags

We regularly perform our spirit of ''Innovation bringing progress, Highly-quality making certain subsistence, Administration marketing benefit, Credit score attracting customers for Heavy Load Ball Linear Motion Guide Rail for CNC Lathe, sincerity and strength ,always maintain approved superior quanlity ,welcome to our factoty for go to and instruction and small business.
We regularly perform our spirit of ''Innovation bringing progress, Highly-quality making certain subsistence, Administration marketing benefit, Credit score attracting customers for Linear Guide and Guide Rail, Our technical expertise, customer-friendly service, and specialized products make us/company name the first choice of customers and vendors. We are looking for your inquiry. Let's set up the cooperation right now!

"Good Products are not afraid to be magnified."

PYG^® Brand

tech-info

PHG65mm-ball-linear-guide

Model	Dimensions of Assembly (mm)		Block size (mm)				Dimensions of Rail (mm)					Mounting bolt size for rail	Basic dynamic load rating	Basic static load rating	weight
	Dimensions of Assembly (mm)		Block size (mm)				Dimensions of Rail (mm)					Mounting bolt size for rail	Basic dynamic load rating	Basic static load rating	Block	Rail
	H	N	W	B	C	L	W_R	H_R	D	P	E	mm	C (kN)	C0(kN)	kg	Kg/m
PHGH65CA	90	31.5	126	76	70	200.2	63	53	26	150	35	M16*50	213.2	287.48	7	21.18
PHGH65HA	90	31.5	126	76	120	259.2	63	53	26	150	35	M16*50	277.8	420.17	9.82	21.18
PHGW65CA	90	53.5	170	142	110	200.2	63	53	26	150	35	M16*50	213.2	287.48	9.17	21.18
PHGW65HA	90	53.5	170	142	110	259.2	63	53	26	150	35	M16*50	277.8	420.17	12.89	21.18
PHGW65CB	90	53.5	170	142	110	200.2	63	53	26	150	35	M16*50	213.2	287.48	9.17	21.18
PHGW65HB	90	53.5	170	142	110	259.6	63	53	26	150	35	M16*50	277.8	420.17	12.89	21.18
PHGW65CC	90	53.5	170	142	110	200.2	63	53	26	150	35	M16*50	213.2	287.48	9.17	21.18
PHGW65HC	90	53.5	170	142	110	259.6	63	53	26	150	35	M16*50	277.8	420.17	12.89	21.18
